Product details

Origin:USA

Brand:A-B

Product ID: 1756-CN2RXT

product description

ControlLogix Communication Module Technical specifications

Ambient temperature (Max) : 60 °C

Storage temperature: -40 to 85 °C

Electromagnetic radiation: meets CISPR 11: Class A standards

Vibration: 2 G @ 10... 500 Hz

Electrostatic discharge (ESD) immunity: 6 kV contact discharge, 8 kV air discharge

EFT/B immunity: ±3 kV on ControlNet port, frequency is 5 kHz

Relative humidity: 5... 95% non-condensing

Impact: Working state: 30G, non-working state: 30G

Conducted radio frequency (RF) immunity: 10V rms, 1 kHz sine wave at 150 kHz to 80 MHz, modulation at 80% AM

Surge transient immunity: ±2 kV line to ground (CM) on the ControlNet port

Operating temperature: 0 to 60 °C

Radiofrequency (RF) immunity:

10 V/m, frequency 80... 1 kHz sine wave of 2000 MHz, modulation of 80% AM

10 V/m, 200 Hz 50% pulse with a frequency of 900 MHz, and the modulation system is 100% AM

10 V/m, 200 Hz 50% pulse at 1890 MHz, modulation system 100% AM

3 V/m, frequency 2000... The 1 kHz sine wave at 2700 MHz is tuned to 80% AM

Overview:

The ControlLogix communication module is a high-performance, highly reliable communication module designed for industrial automation and control systems. It supports a variety of communication protocols and network topologies and can be seamlessly integrated with other modules in the ControlLogix system for efficient data transmission and control functions.

Features:

Wide temperature operating range: Stable operation in storage temperatures from -40 to 85 °C and operating temperatures from 0 to 60 °C.

Strong electromagnetic compatibility: In line with CISPR 11: Class A standards, with excellent anti-electromagnetic interference capabilities.

High vibration and shock resistance: can maintain stable operation in high vibration and shock environment.

Excellent electrostatic discharge and surge transient immunity: able to withstand electrostatic discharge up to 6 kV and surge transients of ±2 kV.

Enhanced RF immunity: Excellent RF immunity over a wide frequency range ensures stable operation in complex electromagnetic environments.

Application scenario:

Industrial automation and control systems requiring high-performance, highly reliable communications.

A control system that requires stable operation under harsh environmental conditions such as high temperature, high humidity, high vibration, etc.

Where efficient data transfer and control with other modules in the ControlLogix system is required.

Installation and configuration:

The communication module should be installed in a suitable location on the ControlLogix system and configured as required. Users can set communication parameters and network configuration through programming software to meet specific communication needs.

Note:

When installing and configuring modules, be sure to follow the manufacturer's guidelines and recommendations.

Ensure that the ambient temperature of the module is within the specified range to avoid performance degradation or damage.

When handling the module, follow the safety regulations and guidelines to avoid electrostatic discharge and other potential risks.

Check the working status and connection of the module regularly to ensure the stable operation of the system.
