Schneider TSXPSY1610M module is a high-performance power module, the following is a detailed
 introduction to the module:

1. Basic characteristics

Model: TSXPSY1610M

Power supply and total power consumption: 24VDC (not isolated), 30W (there are also claims that the
 power of the module is 16W, which may be a small difference between different batches or
 configurations)

Second, functional characteristics

Power supply: The TSXPSY1610M power module provides a stable and reliable power supply for each
rack and rack mounted modules.

Indicator display: The module is equipped with the OK indicator (green), BAT indicator (red), and 24V
 indicator (green) to indicate the power status, battery status, and sensor voltage status.

Hot start function: The module is equipped with a RESET pencil-head button for hot start of the
application, facilitating a quick system restart when needed.

Battery slot: A battery slot is built into the module to protect the processor's internal RAM and ensure
that data is not lost in the event of a system power failure.

Third, appearance and structure

Housing: The module features a robust housing design that protects the cover of the front panel of the
 module from accidental damage.

Terminal block: The module is equipped with screw terminal block for connecting the main power supply,
alarm relay contacts, and sensor AC power supply (depending on model).

Cable clamp window holes: The module is designed with window holes for cable clamps to facilitate cable
fixing and management.

Fuse: The fuse located below the module is used to protect the 24VR voltage on the TSXPSY3610
unisolated DC power supply, ensuring the safe operation of the system.

4. Application and compatibility

Application: TSXPSY1610M module is widely used in industrial automation, process control, machine
manufacturing and other fields to provide stable and reliable power support for PLC system.

Compatibility: The module is compatible with other Schneider automation products such as the
Schneider PLC Premium series and can be easily integrated into existing automation systems.

5. Precautions

When selecting and installing a power module, ensure that the power input of the module matches the
main power supply of the system to avoid damage to the module or system.

Periodically check the indicator status of the module, as well as the status of the battery and fuse to
 ensure the normal operation of the system.

When maintaining or replacing a module, follow the safety regulations to ensure the safety of the
human body and the device.

In summary, the Schneider TSXPSY1610M module is a powerful, stable and reliable power module for a
variety of industrial automation and process control fields.
