As mentioned earlier, this DS200ccag1abb printed circuit board product was produced for GE's now outdated legacy line of logo V-turbine control systems. The larger Mark V series of the DS200cpcag1abb printed circuit board or PCBS is considered a legacy product family because its manufacturing had to stop, occurring many years after its initial release. Although the ds200cpcag1abb PCBS of the larger Mark V series are a traditional series, it is also one of the last GE Mark Series products to utilize their patented high-speed electrical control system technology first released with the Mark I Series concept in the late 1960s. This DS200ccag1abb PCBS was defined in the original Mark V Series instruction manual material as a contactor test plate, although the product originally developed for this particular function would be the DS200ccag1 parent contactor test plate lacking this DS200ccag1abc PCBS triple revision history containing two functional product modifications and one Bizarre artwork configuration modification.

Hardware tips and specifications

Like any Mark V Series product offered to our new and refurbished inventory, this DS200ccag1abb PCB contactor test board is designed to accept various functional induction hardware components through its assembly. The general electric contactor lead board DS200cpcag1abb has one 12-inch connector and two 2-inch connectors. It also features four terminal blocks to connect up to 12 signal lines. The General Electric Contactor driver board DS200cpcag1abb is also equipped with a 24VDC15A receptacle power relay. According to the original instruction manual material for this DS200cpcag1abb device, the various contactor components of the DS200ccag1abb multipurpose circuit board have a specific coil voltage of 115 volts DC. With this voltage in mind, the DS200cpcag1abb contactor control board is able to convert the incoming 115 V AC voltage to 105 V DC voltage, applying a full voltage to turn off its contactor assembly. The high voltage used in the assembly of this ds200cpcag1abb product means that its contactors will remain closed after the first shutdown. In the assembly of the DS200cpcag1abb Mark V Turbine control system family, voltage regulation is achieved through its assembly of various hardware components that limit voltage, including various rectifiers, capacitors and diodes. The DS200ccag1abb circuit board is reinforced to avoid daily wear damage as it is assembled with a thick normal style circuit board surface coating.

There are moving parts inside the relay, so careful consideration is needed when installing boards in the driver. If the relay hits the metal structure or other components in the drive cabinet, it is easily damaged. The relay is high and protruding on the surface of the board, making it easy to hit. When you slide the board into the drive cabinet, make sure you have a good view of the board and the interior of the cabinet. Insert the board slowly and align with the screws on the rack. Insert the screw into the hole with one hand and turn the screwdriver with the other hand to secure the screw. However, do not damage the board by securing it too tightly, lest the screws crack the board. Use washers if they are supplied or used on defective plates. Then, unscrew the screw on the terminal block and insert the wire into the appropriate terminal. Insert the wire into the terminal with one hand and fasten the terminal screw with the other hand. Grab the cable on the connector and plug it into the appropriate connector. Gently press them into the connector to ensure that they are fully secured.
