Product details

Origin:USA

Brand:GE

Product ID: IS200IGDMH1B

product description

The IS200IGDMH1B is a board component for the Mark VI system.  The MKVI is part of

the Speedtronic line of gas/steam management systems that GE has had in development since

 the first Mark I was put into service in the late 1960s.  The Mark VI includes a PC-based HMI

(operator interface) that allows users to access most system data from a single location, including

 time tags for events and alarms.

The IS200IGDMH1B functions as IGBT Gate Driver board.  This is a small rectangular board

that does not have a faceplate.  The board is connected to a sub-strata that consists of a

moldable white material.  The faceplate is marked with the GE logo and with the board ID

 number.

The  IS200IGDMH1B is built with two transformers, over ten integrated circuits, resistors, resistor

 network arrays, capacitors, diodes, and multiple connectors of various types.  This includes two

 vertical male two-pin connectors, marked J1 and J2, and a single pin connector marked J3. The

 board has two plastic components that are also connectors and several terminal connections.

The board has several transistors. It also has an auxiliary board that is soldered to the primary

board. The auxiliary board carries several additional components, including capacitors. This board

 is placed back-to-back with a heat sink component.

 for the IS200ICBDH1ABB made by GE.
