[Product Description]:

The Allen-Bradley 1756-LSP is a GuardLogix safety partner controller. It has 250 connections but it does not have any user memory for standard tasks. Its safety memory depends on the memory of the corresponding primary controller. Its main purpose is to provide a redundancy, a second channel that is isolated for the system's safety-related functions. This controller has current draws of 1200 mA at 5.1V DC and 14 mA at 24V DC. Its power dissipation is 3.5 W and its thermal dissipation is 11.9 BTU/hr. The isolation voltage is a continuous 30V which is basic insulation that has been type-tested from RS-232 port-to-system at 720V DC for 60 seconds. Its operating temperature is from 0-60 ËšC and its non-operating temperature is from -40-85 Deg. C. It also comes with a maximum surrounding air temperature of 60 Deg. C. and a non-condensing relative humidity of 5-95%. Its operating shock is 30 g, its non-operating shock is 50 g, and its operating vibration is 2 g at 10-500 Hz. The configuration of the 1756-LSP safety partner is dependent on the primary controller since it does not have its own key switch and communication port although it has an RS-232 port. It comes with a battery for the clock and backup power. The controller also has LED status indicators allowing you to monitor its current state. The controller ships with a nonvolatile memory, a CompactFlash card to be exact. It measures 27 x 17 x 7 centimeters and weighs 0.7 lbs. The 1756-LSP safety partner is used for the 1756-L61S, 1756-L62S, and the 1756-L63S controllers. It should be installed in the slot to the right of the primary controller to satisfy SIL 3 requirements. It also has an open-type enclosure.

[Our main products]:

DcS system card of ABBPLC includes some discontinued control system module card. (For example, PM645B, 5SHY3545L0014, PM630, 07AC91D, SPHSS13, PP845PFEA111-20, PFEA112-65 PPD113B01-10-150000, PPD115A102, PPD113-B03-23-111615)

◆GE Gas Turbine clamp :IS200 series, DS200 series, such as IS200TRPGH1B, DS20OPCCAG1A.

◆Triconex: Redundant fault-tolerant control system, modern fault-tolerant controller based on triple module redundancy (TMR) architecture. (For example, 3721, 3625, 3008, 4351B, 3805E)

◆Foxboro(Foxboro):1/ASeries system, FBM(field input/output module) sequence control, etc. (e.g. FBM201, CP270, CP4OB, FCP280, FCP270)

◆BentlyNevada(Bentley): Card of the 3500 system. (Example :3500/15, 3500/22M, 3500/42M)

◆ HIMA(Dark horse):F8650X, F8627X, F8651XF8652X, F35 etc

◆Motorola :MVME162, MVME167, MVME1772, MVME177 and other series

◆X001:1/0, Vne board and processor. (Example :XVME-653, XVME-674, XVME-976)

◆Rockvell(Allen-Bradley): Series 1756, 1757, 1753 and 1394. (Example :1756-L73XT, 1756-L61, 1757-SRM)

◆Reliance: Spare parts (e.g., 0-60002-6, S-D4022, S-D4006-D)

◆Westinghouse Emerson :VE3007, CE3008, 5X00105G14, 5X00119G01, 1X00416H011X00416H01

◆Schneider :140 series processor, control card, power module, etc. (For example, 140CPU67160C, 140CPU67260, 140CPU65150, 140CPU43412, 140NWM110000

◆ABB: Industrial robot DSQC series (series :DSQC202, DSQC545A, DSQC627, DSQC352, DSQC679)

◆Rexroth :1/0 module PLC controller driver, etc. (For example, TVD1.3-15-03, KDV3.1-100-220

◆Woodward: Control governor, etc. (e.g. 5644-414, 5466-409, 9907-164)

[Order please contact us]:

Contact :15339537573(same wechat number)

QQ： 2054523139

Mail box：2054523139@qq.COM

Note; All the products on this site are special products, the market price has been fluctuating, the specific customer service quotation shall prevail, the product models are many, can not be uploaded one by one, if there is not found the model, can contact customer service at any time. Store product price, not real price, before bidding please contact customer service for accurate price and delivery time, sorry for the inconvenience to you!

We will let time prove that your choice is not wrong! We will use sincere service in exchange for your 200% satisfactionHigh quality low price spot to provide your satisfaction is our goal for effortsCooperative customers, before ordering can provide the qualification and the recent sales issued the scanning copy of the bill for inquiry.After-sales problems: Execute according to the brand manufacturer's standard, guarantee after-sales service, one-year warranty for all products, etc

[Disclaimer]

Guizhou Yuanmiao Automation Equipment Co., LTD. We sell new products and discontinued products, independent channels to purchase such special products. Guizhou Yuanmiao Automation Equipment Co., Ltd. is not an authorized distributor, distributor or representative of the featured products on this website. All product names/product images, trademarks, brands and logos used on this website are the property of their respective owners. Descriptions, descriptions or sales of products bearing these names, images, trademarks, brands and logos are for identification purposes only and do not imply any association or authorization with any rights holder
